1. What industry standard does this insulator comply with?
This product is manufactured strictly according to the ANSI C29.5 standard, ensuring reliable performance in electrical distribution systems.
2. What is the mechanical strength rating for this unit?
The combined Mechanical and Electrical (M&E) strength is rated at 3,000 lb (13.3 kN).
3. What are the electrical flashover limits for wet and dry conditions?
The low frequency dry flashover voltage is 100 kV, while the low frequency wet flashover voltage is 50 kV.
4. What is the leakage distance of this insulator?
The leakage distance is 15 inches (381 mm), providing excellent surface tracking resistance.
5. How is the product packed for shipping?
Each unit has a net weight of approximately 9.1 lb (4.1 kg), and they are typically shipped in quantities of 144 units per pallet.
6. What is the maximum Radio-influence Voltage (RIV)?
At a test frequency of 1000 kHz, the maximum RIV is 100 μV with a test voltage of 22 kV rms to ground.
